Nano-Engineered SHT Zirconia Block , 0.15μm Grain Size , CIP Manufacturing

Brand Name: LeoTech
Model Number: SHT-White
MOQ: 5 boxes
Price: $13.00-50.00/boxes
Detail Information
Place of Origin:
Chongqing, China
Certification:
CE
Power Source:
Manual
Warranty:
1 Year
After-sale Service:
Online Technical Support
Material:
Zirconia
Shelf Life:
1years
Quality Certification:
Ce
Instrument Classification:
Class II
Safety Standard:
None
Product Description
Nano-Engineered SHT Zirconia Block , 0.15μm Grain Size , CIP Manufacturing
Achieve micron-level accuracy with SHT's nano-structured zirconia (average grain size: 0.15μm). Fabricated via cold isostatic pressing (CIP) at 300MPa, the blocks eliminate porosity for flawless sintering. The optimized Y₂O₃ gradient (7.0-7.8%) enables controlled shrinkage of 20.5±0.3% at 1500°C.

Manufacturing Excellence

  1. Powder Synthesis: Plasma atomized nano-powder

  2. CIP Processing: 300MPa uniform compression

  3. Pre-Sintering: 1150°C for handling stability

  4. QA Testing: 100% density scan

Precision Metrics

  • Shrinkage Consistency: ±0.3%

  • Surface Defects: <0.1/cm²

  • Dimensional Tolerance: ±0.05mm

Nano-Engineered SHT Zirconia Block , 0.15μm Grain Size , CIP Manufacturing 0
Nano-Engineered SHT Zirconia Block , 0.15μm Grain Size , CIP Manufacturing 1





Features
Safe high quality raw material
● Excellent aesthetic and strength
● Seven layers natural shade gradient, the preferred and most common multilayer material used for posterior restoration
● Reliable manufacture, ODM&OEM available


Technical Information
Nano-Engineered SHT Zirconia Block , 0.15μm Grain Size , CIP Manufacturing 2


color-shades
Nano-Engineered SHT Zirconia Block , 0.15μm Grain Size , CIP Manufacturing 3

indications for use
Nano-Engineered SHT Zirconia Block , 0.15μm Grain Size , CIP Manufacturing 4

Product paramenters
Model SHT-White
Size 98mm,95mm,92*75mm
Translucency 46%
Sizes 10mm/12mm/14mm/16mm/18mm/20mm/22mm/25mm
Strength 1000 MPa

ST/SHT/SHT-ML Sintering

Max Heating rate: 10℃ per minute
Final temperature: 1500℃-1550℃, 1530℃ is best
Holding time at final temperature: 2 hours
Cooling should be done without temperature control in closed furnace
Never open the furnace before it has reached a temperature of less than 80℃ to avoid thermal shocks

Sintering charts:

Nano-Engineered SHT Zirconia Block , 0.15μm Grain Size , CIP Manufacturing 5




ODM&OEM Avaliable
Nano-Engineered SHT Zirconia Block , 0.15μm Grain Size , CIP Manufacturing 6
Nano-Engineered SHT Zirconia Block , 0.15μm Grain Size , CIP Manufacturing 7
Nano-Engineered SHT Zirconia Block , 0.15μm Grain Size , CIP Manufacturing 8


Why choose us?
Nano-Engineered SHT Zirconia Block , 0.15μm Grain Size , CIP Manufacturing 9


Factory Display
Nano-Engineered SHT Zirconia Block , 0.15μm Grain Size , CIP Manufacturing 10


Packing&delivery
Nano-Engineered SHT Zirconia Block , 0.15μm Grain Size , CIP Manufacturing 11


FAQ

1. Who are we?
We are a professional medical device supplier located in Chongqing, the middle of China. We concentrates on clinical medical equipment development and production by working with our quality factories and scientific institutes. By offering one stop service on medical device, our experienced staff members are always available to discuss your requirements and ensure full customer satisfaction.

2. How can we guarantee quality?
CE certificates and ISO quality control system are essential.
Production data and update would be provided during manufacturing.
Final inspection and testing are always done before shipment.

3. Why should you buy from us rather than other suppliers?
10+ years experience at medical & health care industry makes us more professional.
Not just one stop service, but also the resources integration service that we are offering, to help our customer to win the
market.

4. How can you get your quotation as soon as possible?
You can send us messages by trade manager, email, whatsapp, facebook, Instagram or phone call, tell us your interested items,
quantity, destination, and other detail requirements. We will reply you as soon as possible.

5. Can we provide RTS / fast delivery services?
Yes, we do. Please find our RTS page and place the order, or contact our manager. We will deliver your require items in 15 days as
soon as we confirmed the order and received the payment.

6. Can we provide OEM/ODM service?
Yes, we offer OEM/ODM service if your buying quantity comes to the certain number, which depends on difference items. Please
contact our manager for further information.
