PEEK Dental Discs 160MPa+ Strength, Zirkonzahn & Amann Girrbach Compatible CAD/CAM

Brand Name:	Leomed

Detail Information

Product Description

Detail Information

Productn Name:

PEEK

Color:

Natural/White/Yellow/Red

Density(g/cm3):

1.32/1.48/1.51/1.35

Bending Strength(MPa):

163/152/154/158

Bending ModulusBending ModulusBending Modulus(GPa):

4/5.3/5.6/4.8

Bending Modulus(KJ/m2):

199/145/162/176

Product Description

PEEK Dental Discs 160MPa+ Strength, Zirkonzahn & Amann Girrbach Compatible CAD/CAM

Medical-Grade PEEK Dental Discs
Engineered as the ultimate bone-mimetic solution for permanent implant prosthetics, these semi-crystalline PEEK discs deliver revolutionary biomechanical performance. With an elastic modulus (4-5.6 GPa) mirroring cortical bone and flexural strength exceeding 160MPa, they eliminate stress-shielding risks while enabling precision CAD/CAM fabrication at 260°C.

Biomechanical Superiority

Stress-Shielding Elimination – 4.0-5.6 GPa modulus matches human bone for load distribution
Fatigue-Resistant Architecture – >160MPa flexural strength supports multi-unit bridges
Bioinert Certification – ISO 10993-compliant surface inhibits bacterial colonization
Imaging Compatibility – Zero CT/MRI artifacts for accurate diagnostics

Clinical Advantage Matrix

Property	PEEK Discs	Titanium	PMMA
Elastic Modulus (GPa)	4.0-5.6	110-120	2.0-3.0
Density (g/cm³)	1.32-1.51	4.4-4.5	1.15-1.19
Allergy Incidence	0%	>8%	<0.1%
Aesthetic Adaptability	Tintable (★★★★☆)	Non-adaptable	High (★★★★★)

Precision Fabrication Protocol

Tooling Requirements

Diamond-coated carbide burs
18,000-25,000 RPM spindle speed
≥0.75 MPa vacuum pressure

Post-Processing

Sandblasting – 50μm alumina oxide
Staining – PEEK-specific dyes (80°C/10min)

Clinical Applications

Healing Abutments – 37% ↑ osteoblast proliferation vs titanium
Removable Dentures – 60% lighter than cobalt-chrome
Surgical Guides – Withstands 200+ autoclave cycles (134°C)

Product Specifications

Grade	Density (g/cm³)	Flex Strength (MPa)	Modulus (GPa)
Natural	1.32	163	4.0
White	1.48	152	5.3
Yellow	1.51	154	5.6
Red	1.35	158	4.8

PEEK Dental Discs 160MPa+ Strength, Zirkonzahn & Amann Girrbach Compatible CAD/CAM 0

PEEK Dental Discs 160MPa+ Strength, Zirkonzahn & Amann Girrbach Compatible CAD/CAM 1

PEEK Dental Discs 160MPa+ Strength, Zirkonzahn & Amann Girrbach Compatible CAD/CAM 2
