Dental Titanium Disc: Grade 5 Ti-6Al-4V for CAD/CAM. High-strength, low-density, corrosion-resistant, biocompatible—for long-term prosthetics & implant structures. Mill custom abutments/frameworks; digital casting alternative. Dia 95/98.5 mm; thick. 8–25 mm. Flexible for CAD/ CAM
Dental titanium disc
,Grade 5 Ti-6Al-4V Dental titanium disc
,Implant abutment framework Dental titanium disc
Dental Titanium Disc Grade 5 Ti-6Al-4V 950–1200 MPa CAD / CAM
Product Overview
Dental Titanium Disc is a Grade 5 titanium alloy material (Ti-6Al-4V) designed for CAD / CAM dental machining. With high mechanical strength, low density, corrosion resistance and good biocompatibility, it is suitable for manufacturing long-term dental prosthetic components and implant-supported structures. The disc can be milled into custom implant abutments, implant-supported frameworks and removable prosthetic frameworks, providing a digital alternative to conventional casting workflows. Available in 95 mm and 98.5 mm diameters with 8–25 mm thickness options, it gives dental laboratories flexibility for different CAD / CAM designs.
Key Advantages
| Feature | Benefit |
|---|---|
| Grade 5 Ti - 6AI - 4V | Widely used titanium alloy for high - performance dental applicaitons |
| High Strength | 950 - 1200 MPa specified flexual strength |
| Biocopatible Material | Suitable for selected long-term dental and implant - supported applicaitons |
| Corrosion Resistance | Supports durability in the oral environment |
| CAD / CAM Milling | Enables digitally designed and precisely milled dental components |
| Flexible Dimensions | 95 / 98.5 mm diameter and 8 - 25 mm thickness |
Digital Dental Applications
Titanium discs are primarily used as milling blanks for:
- Custom Implant Abutments – Connecting components between implants and crowns
- Implant-Supported Frameworks – Frameworks for implant-supported restorations
- Removable Prosthetic Frameworks – Metal frameworks for selected removable prostheses
Compared with conventional casting-based production, CAD / CAM milling allows the restoration geometry to be generated directly from a digital design, supporting consistent and precise manufacturing.
Grade 5 Ti-6Al-4V titanium disc for CAD / CAM dental machining.
Dental titanium discs in standard diameter and thickness configurations.
FAQ
What is a dental titanium disc used for?
It is used as a CAD / CAM milling blank for manufacturing custom implant abutments and dental prosthetic frameworks.
What titanium grade is used?
The material is Grade 5 Ti-6Al-4V titanium alloy.
What sizes are available?
The discs are available in 95 mm and 98.5 mm diameters, with thicknesses from 8 to 25 mm.
Why is Grade 5 titanium suitable for dental applications?
Grade 5 titanium combines high strength, low density, corrosion resistance and good biocompatibility, making it suitable for selected dental and implant-supported applications.
